QDT5070GPS series 5 stere green watering truck
- Independent research and development, with multiple work modes
- The tank body has a rectangular and circular shape, with a transition between the tank body and the side wall arc, making the overall proportion of the vehicle coordinated and aesthetically pleasing
- Spray alloy paint inside the tank for corrosion prevention and rust prevention
- Adopting high-efficiency two-stage self-priming centrifugal water pump, with a large flushing width
- The rear sprinkler device can be adjusted 360 degrees, covering a wide range and saving water
- The water flow of the spray gun can be adjusted in two states: mist or jet, to meet different needs
- The vehicle has a large water carrying capacity and a long working time
- Standard electronic control system, adopting centralized control of electricity and gas, can control each nozzle in the driver’s cabin
- Equipped with a 30 meter fog gun, remote control, high intelligence, and reduced labor intensity
China's leading manufacturer of various light, medium and heavy trucks and large buses
Our Products
Contact Us
Main technical parameters
| 项目名称 Project Name | 技术参数technical parameter | |
| 整车参数 Vehicle parameters | 底盘型号 Chassis Model | 东风、解放、重汽、陕汽、福田等 DFL，FAW，CNHTC，SHACMAN，FOTON，ETC |
| 燃料种类及排放标准 Fuel types and emission standards | 柴油、国二以上排放 Diesel, National Phase II Automotive Emission Standards and above | |
| 整备质量（kg） Curb weight (kg) | 3490 | |
| 外型尺寸(长×宽×高)(mm) External dimensions (length x width x height) (mm) | 5995×1970×2350 | |
| 轴距(mm) Wheelbase (mm) | 3360 | |
| 专用装置作业参数 Special device operation parameters | 最大容积(m) Maximum volume (m) | 5 |
| 洒水泵型 Sprinkler pump type | 80QZ-45/60N | |
| 洒水宽度(m) Sprinkler width (m) | ≥12 | |
| 冲洗宽度(m) Flushing width (m) | ≥16 | |
| 后喷枪射程(m) Rear spray gun range (m) | ≥25 | |
| 额定流量(m³/h) Rated flow rate (m ³/h) | 45 | |
| 以上数据参数仅供参考，具体数据以实车为准 The above data parameters are for reference only, and the specific data shall be subject to the actual vehicle | ||
