Aerial truck
Qingte brand aerial work trucks include electrified and non-electrified types, with folding boom, hybrid boom and telescopic boom, the maximum working height covering 12-34 metres, and can be equipped with A-type, H-type, frog-type outriggers or no outriggers, and the outriggers can be configured with automatic leveling and non-automatic leveling control according to the requirements; a variety of models can be matched with robotic work modules to achieve linked operations. A variety of models can be matched with robot operation module to realise linkage operation. There are also tracked insulated bucket trucks that can be remotely operated and work in multiple terrains. The vehicles are equipped with complete safety protection system to ensure the safety of operators.
China's leading manufacturer of various light, medium and heavy trucks and large buses
Our Products
Contact Us
Aerial truck product features
- Complete safety protection system: it has complete safety protection system such as interlocking of loading and unloading, soft leg protection, horizontal outrigger non-extension
- limiting slewing, emergency stop, etc. to ensure the safety of operators;
- The key components are all international famous brands, reliable performance and smooth action;
- Electro-hydraulic proportional control, stepless speed regulation, superior operating performance;
- H-type outriggers with large outrigger span, stable and reliable support, horizontal and vertical expansion and contraction can be controlled individually;
- Lightweight design, light weight and compact structure of the whole vehicle;
- The turntable and work hopper are operated from two places, and both can remotely control the engine ignition and shutdown;
- Bus modular control system, complete and reliable safety protection system
Main technical parameters
| 项目名称 Project name | 技术参数 Technical parameters |
| 作业高度（m） Operating height (m) | 14～28 |
| 作业幅度（m） Operating range (m) | 8.1～14 |
| 工作斗额定载荷（kg） Rated load of working bucket (kg) | 200 |
| 转台旋转角度（°） Rotary table rotation angle (°) | 360 |
| 工作斗旋转角度（°） Working hopper rotation angle (°) | 180 |
| 支腿调平方式 Leg leveling method | 自动调平、手动调平、单独可调 Automatic leveling, manual leveling, individually adjustable |
| 底盘 Chassis | 庆铃、江铃 Qingling, Jiangling |
