Lighting vehicle
Mobile lighting vehicle is used to provide on-site mobile lighting at night when there is no other lighting source for field operation, emergency rescue, accident repair and handling of abnormal situations.
China's leading manufacturer of various light, medium and heavy trucks and large buses
Our Products
Contact Us
Product Features
- Lifting lighting device chooses three sections of telescopic cylinders as the lifting and adjusting method, the maximum height of 6.5 metres, can be rotated horizontally 380 °, vertical rotation 330 °, the light covers a large area;
- The light source has a long life span of more than 10,000 hours, especially suitable for outdoor lighting;
- Adopting high-performance generator set for power supply, it can also be connected to 220V AC power supply to achieve long time lighting in places with utility power;
- Offline remote control and online remote control two ways to control the lifting bar lifting, rotation and lighting switch, simple operation, safe and reliable.
Main technical parameters
| 项目名称Project name | 技术参数Technical parameters |
| 升降照明灯杆数（套） Number of lifting lighting poles (sets) | 1 |
| 升降照明灯功率（W） Lifting lamp power (W) | 6×1000 |
| 系统工作电压（V） System operating voltage (V) | AC220/380 |
| 系统工作电流（A）（≤） System operating current (A) (≤) | 30 |
| 光源型式 Light source type | 金卤灯（泛光/聚光） Metal halide lamps (flood/spot) |
| 光源色温 Colour temperature of light source | 6500K |
| 光源颜色 Colour of light source | 自然光色 Natural light colour |
| 水平垂直旋转速度（r/min）（≥） Horizontal vertical rotation speed (r/min) (≥) | 4 |
| 光通量（Lm）（≥） Luminous flux (Lm) (≥) | 320000 |
| 灯杆升高高度（m）（≥） Lamp post elevation (m) (≥) | 6.5 |
| 灯具离地高度（m）（≥） Lamp height above ground (m) (≥) | 7 |
| 灯杆形式（套） Light pole form (set) | 伸缩杆，独立自动升降、旋转（离线遥控+在线控制） Telescopic pole, independent automatic lifting and rotation (offline remote control + online control) |
| 水平旋转角度（°）（≥） Horizontal rotation angle (°) (≥) | 380 |
| 垂直旋转角度（°）（≥） Vertical rotation angle (°) (≥) | 330 |
| 有效照射距离（m）（≥） Effective irradiation distance (m) (≥) | 50 |
