Mobile vehicle transformer
The design of mobile transformer vehicle with automatic phase sequence checking and synchronisation checking ensures that the mobile transformer vehicle can be safely connected to and withdrawn from the utility network. It realises that when the transformer of the utility network is under maintenance or replacement, the load side will not be powered.
China's leading manufacturer of various light, medium and heavy trucks and large buses
Our Products
Contact Us
Product Features
- The high-voltage side switch, transformer and low-voltage output switch must be separated from each other in three rooms and arranged in separate areas without mutual influence.
- Variable coupling group, applicable to different groups of column transformers in parallel.
- Multiple noise reduction treatments to ensure low vehicle noise.
- Output mode is quick connector and copper row output mode, convenient and practical.
- Cable reel adopts chassis taking force and hydraulic power, which can realise single disc or multiple discs to be put away and put down at the same time.
- The centralised control of the operation panel can realise the direct output of the box-variable vehicle, automatic checking of the same period, automatic checking of the phase
- sequence, and no-voltage self-submitting and cutting functions.
Main technical parameters
| 项目名称 Project name | 技术参数 Technical parameters |
| 变压器形式 Transformer form | 干式变压器 Dry-type transformers |
| 容量（kVA） Capacity (kVA) | 400/630/800 |
| 电压变比 Voltage Ratio | 10.5kV±2×2.5%/0.4kV |
| 联结组别 Linkage group | Dyn11/Yyn0 |
| 环网柜形式 Ring cabinet form | 三单元SF6 Triple unit SF6 |
| 高压电缆数量/每根米数 Number of high voltage cables/metre each | 3/30 |
| 低压电缆数量/每根米数 Number of low voltage cables/metre each | 8/50 |
| 功能 Functionality | 直接输出、自动检相序、自动检同期 Direct output, automatic phase sequence detection, automatic simultaneous detection |
